Plant Imaging System
PlantView Bioluminescence Imaging Series
BLT-PlantVIew, exceptionally sensitive plant bioluminescence imaging system. The BLT-PlantView100 incorporates a back-illuminated ultra-low temperature CCD camera, renowned for its remarkably high detection sensitivity. The dark cabinet effectively shields the imaging process from external light. The optional Lateral Imaging Module, which features a rotating stage, and the included adjustable plant growth simulation software, facilitates extended multi-site imaging under highly controlled light conditions. This design enhances system performance and reliability. The user-friendly software interface simplifies operation and allows experimental programmes to be pre-set.
Features - BLT-PlantView 100
- Deep-cooled, research-grade CCD camera with temperatures down to absolute -100°C (-148°F), with capability to capture weak fluorescence / luminescence (QE >95% @ 520－630 nm, 80% @ 460-780 nm)
- High resolution CCD camera, 1024 x 1024 px, 13 x 13 µm size; dynamic range 90 dB
- Five sets of excitation and emission filters included, 465 nm to 820 nm (see specs for details)
- Large field of view (top; 280 mm x 280 mm), for small plants, seedlings, seeds, fruits, culture dishes etc.; F0.95 wide-angle lens
- Plant light simulation module, for plant growth rhythm and photoperiod experiments; with cooling
- Global shadowless, uniform LED excitation mode
- User-friendly software included (English); free software upgrades
Optional
- Lateral imaging module, for dual imaging (top and side), field of view: 120 mm x 100 mm; includes sample rotation platform, and 100 mm square culture dish adaptor (available also separately)
- Expanded excitation range (capacity: 20 excitation lights, 10 filters)
-
- UV transluminator: 306 nm
- Blue light transluminator: 470 nm
| Specifications | BLT-PlantView 100 | OPEN |
As a cost-effective alternative for Chlorophyll Fluorescence Imaging, without light and closed chamber design (as in the BLT-PlantView 100), consider the BLT-PlantView 230F Imager.
For combined imaging of roots in rhizoboxes and shoots, see the fully automated, standardized rhizobox imaging platform.
If root imaging in the RGB range is of interest, consider the manual MR or automatic minirhizotron systems for in situ use.
